30000 TPY Angle Steel Rolling Production Line

Features
Process
Parameters
Services

Features

Increased Productivity: The automation eliminates the need for manual intervention and reduces downtime, resulting in higher production rates. It can operate continuously, 24/7, with high-speed and consistent output.
Improved Efficiency: Automation streamlines the steel rolling process, minimizing human error and optimizing resource utilization. The production line can be fine-tuned to achieve precise dimensions, tolerances, and surface finishes, leading to improved quality control and reduced material waste.
Enhanced Workers’ Safety: By automating hazardous and physically demanding tasks, automatic rolling production lines improve workplace safety. Workers are exposed to fewer risks associated with heavy machinery, extreme temperatures, and repetitive motions, reducing the likelihood of accidents and injuries.
Flexibility and Customization: Automatic rolling production lines can be programmed to produce various steel products with different dimensions, profiles, and surface finishes. This flexibility allows manufacturers to respond quickly to changing market demands and customer requirements, enabling customization and reducing lead times.
Data Monitoring and Analysis: Automation enables comprehensive data collection and real-time monitoring of the rolling process. This data can be analyzed to identify trends, optimize performance, and proactively detect and address potential issues. Continuous improvement initiatives can be implemented based on data-driven insights.

Process

Parameters

Specification and Technical Parameter
Capacity (T/Year)	Capacity (T/Hour)	Working Hours(Year)	Melting Furnace	CCM		Rolling Mill			Space (㎡)	Electricity Consumption	Finnal Product Diameter
Capacity (T/Year)	Capacity (T/Hour)	Working Hours(Year)	Melting Furnace	Model	Billets	Rough Mill	Middle Mill	Finish Mill	Space (㎡)	Electricity Consumption	Finnal Product Diameter
10000	4	2400	1.5T*3	R2.5	50*50	FF280*3	FF250*2	FF220*2	80*15	4.5MW	Rebar, Angle Ø6-32mm
12000	5	2400	2T*3	R2.5	60*60	FF280*3	FF250*2	FF250*2	120*20	5MW	Rebar, Angle Ø6-32mm
20000	8	2400	3T*3	R2.5	70*70	FF350*3	FF280*2	FF250*2	120*20	8.5MW	Rebar, Angle Ø6-32mm
40000	10	3600	3T*4	R3.5	90*90	FF380*3	FF300*2	FF280*2	150*20	9.5MW	Rebar, Angle Ø6-32mm
50000	15	3600	5T*3	R5.5	120*120	FF450*3	FF350*2	FF280*2	180*20	10MW	Rebar, Angle Ø6-32mm
100000	16	6000	5T*4	R6*2	120*120	FF450*3	FF400*2	FF280*2	120*32	15MW	Rebar, Angle Ø6-32mm
200000	35	6000	10T*4	R6*2	150*150	FF550*3	FF450*2	FF280*2	180*32	26MW	Rebar, Angle Ø6-32mm
Note: The above configuration is for reference only and can be adjusted according to the venue provided by the customer

Services

The basic layout of equipment and plant layout can be provided
Provide after-sales service, we have installation engineers stationed overseas all year round, who can go to your factory to install and debug the machine
Competitive price and good quality
The equipment has stable performance and has been running stably in many countries around the world for more than 5 years
Suitable production solutions can be customized according to different customer needs
The production capacity can be adjusted according to customer requirements
