The laying machine is one of the key supporting equipment in the rolling mill production line. Its main function is to evenly lay out the hot-rolled wire at high speed and form a regular coil structure to facilitate subsequent cooling, transportation and packaging. The equipment has stable operation and compact structure, and is an indispensable and important machine for modern wire production lines.

Consult Online [email protected]

Product Introduction
Application
Product Advantages
Product Structure

Product Introduction

The laying machine is one of the key supporting equipment in the rolling mill production line. Its main function is to evenly lay out the hot-rolled wire at high speed and form a regular coil structure to facilitate subsequent cooling, transportation and packaging. The equipment has stable operation and compact structure, and is an indispensable and important machine for modern wire production lines.

Application

Hot-rolled wire production line in rolling mill
Wire and bar production enterprises
High-speed wire laying process scene
Round steel and steel bar coil output equipment
Automated cooling and conveying system supporting equipment

Product Advantages

Simple structure, stable operation, few core components, easy maintenance, long life.
Adapt to high-speed spinning process, suitable for high-line production line, fast spinning speed and stable trajectory.
Wire out neatly, beautiful loops are equipped with guide devices to ensure uniform looping of wire.
Strong wear resistance The guide plate is made of wear-resistant steel to extend the service life. Low energy consumption, low maintenance cost, high transmission efficiency, small mechanical wear, energy saving and environmental protection. Strong adaptability, can be used with various specifications of rolling mills and cooling conveyor lines.

Product Structure

The wire laying machine is an important equipment used in wire rolling or coil production lines to make hot-rolled wires neatly and continuously lay out wires into coils. The main structural components are as follows:
Spindle part
The spindle is a high-strength steel shaft body processed as a whole, supported on the frame by bearings to ensure smooth rotation.
The end is connected to a rotating disk or a wire guide disk.
The rotating disk/wire guide disk
is used to guide the wire to rotate at high speed, and the disk surface is provided with a guide groove or a direction adjustment mechanism. It is made of highly wear-resistant materials.
Transmission system
Generally, the flywheel is driven by a motor, connected to the spindle through a belt or a coupling, and drives the rotation to lay out wires.
A reducer and a frequency conversion control system can be configured to adjust the laying speed.
The frame structure adopts channel steel or welded steel structure, which has good stability and seismic resistance.
It can be installed on the ground or on a platform.
